Infinity All-In-One PC

24" or 22" Medical-grade PC with dual hot-swappable batteries.

Our new 4th generation Infinity PC is a best of breed solution which has resulted in many successful EPR and ePMA large project roll-outs. ‘All-In-One’ means IT teams do not have to purchase a separate PC, monitor and battery supply. We combine all of those things in one solution at the forefront of IT with clinical benefits at the core.

The platform combines a high-performance CPU, up to 23% faster single
thread performance, and up to 19% faster multi-thread performance. With
new Intel® Iris® Xe graphics, the platform offers up to 2.95 times faster
graphics performance, plus PCI Express 4.0 and Thunderbolt™ 4/USB4.

The processors can support low-latency and time-sensitive applications, and have the power to
run multiple workloads including AI and deep learning applications on a single
platform.

Naturally, the Infinity PC retains its signature feature of dual hot-swappable
batteries. The hot-swappable battery design allows any Infinity PC with 0%
batteries to come immediately back to full power without the need to wait
for charging.

The new Infinity PC is still compatible with the original battery
system, but we have strengthened the waterproofing of the battery bay,
as well as simplified the battery switch-out process, improving from the
original 3 second, two-step process to a one step execution that takes
only 1 second.

Differing from the traditional Windows screensaver, the Infinity Smart
Screensaver can automatically log out and close the screen in just a few
seconds after a user walks away from the computer, protecting sensitive
information and increasing power savings. The Infinity Smart Screensaver is
simple to set up through our exclusive IR technology and does not require
any personal information. Even wearing a mask does not affect its
functionality.

Our remote battery management system is free for all Infinity PC users. It lets IT teams remotely manage PCs and batteries, to get more out of battery life. By triaging problems remotely, IT teams can save countless hours and also save costs on procuring new batteries by making the most of Infinity PC batteries.

Specifications

ProcessorIntel® 10nm 11 gene. Tiger Lake i7/i5/i3/Celeron
System MemoryDDR4 up to 16GB
OS SupportMicrosoft® Windows 11
Microsoft® Windows 10 (64bit)
Ubuntu 20.04 LTS
IGEL (thin client solution)
GraphicsIntel® UHD Graphics
Storagem.2 SSD up to 512 GB
Wireless Communication802.11 ac/a/b/g/n + BT 4.1 (optional)
Wifi6 + BT 5.2 (optional)
TouchPCT (optional)
Speaker3W x2
Trusted Platform ModuleTPM 2.0
SecuritySmart Card Reader (optional)
Imprivata RFID reader (optional)
Barcode reader (optional)
Waterproof

Front IP65 ; rear IPX1

Display Size21.5” & 23.8″
ResolutionFHD 1920 x 1080
Max. Colours16.7 M
Contrast Ratio3000:1
Luminance (cd/m2)     250
USB             Rear I/O :USB 3.0 x2, USB 2.0 x2
Front button I/O : USB 3.0 x2
Video OutHDMI 1.4 x1
COMCOM port x2
AudioCombo audio port x1
Ethernet1.5kv isolated Gigabit LAN x2
DC-in19V DC-in x1
VESA75/100 mm VESA mount
Operating Temperature0°C ~40°C( 32°F ~104°F)
Storage Temperature-20°C ~ 60°C(-4°F ~ 140°F)
Storage Humidity10%~95%@35°C, non-condensing
Dimension510(L) x 78.4(W) x 346(H)
Net Weight6kg

One PC that suits every workflow

Our All-In-One PC can be used on any of our Carts, Wall mounts or on Anaesthesia Machines. We mount them in different locations to suit the workflow required. The combination of a slim PC that’s designed for frequent cleaning means it is suited for each and every Hospital department.

Infinity PC - Carts

We transformed how clinicians use mobile Carts with the introduction of PCs with hot swappable batteries. There is no need for wires or to plug in at a wall. Clinicians can stay in front of patients at all times, with no need for downtime with 24/7 constant power.

Infinity PC - Wall Mounted

When space is a premium, it’s even harder to access IT equipment. However, in congested areas clinicians still need to access digital records. Often, wall mounted PCs are chosen as they can be flush to a wall and provide a compact, ergonomic PC workstation.

Anaesthesia Workstations

Accessing IT is common in every area now, and that’s recently expanded to Anaesthesia Workstations. Many users are looking at ways to access a PC, while making the configuration is ergonomic, cleanable and compliant with patient safety standards.

Our Services

Get it right first time

We offer a full range of customisable value-added services to help your projects run smoothly and ensure success. Choose which services suit your needs to help get your project right first time.

Framework Supplier

Initial Assessments

Project Management

Installation Services

Device Configuration

Flexible Deliveries

Super User Training

After Sales Support

Configured. Ready for instant roll-out.

The Complete Workflow Solution

IT teams are stretched and the last thing they want is a flat packed or half configured solution. Meanwhile project managers or procurement don’t need to source different accessories from multiple suppliers. We provide everything from scanners, printers, medical keyboards, mice and we’ll also configure your Trust ‘image’ too. This means everything will be ready for instant roll-out, and ready to help with patient care.

We pre-configure the PC with the Trust 'image' to save the IT team time and money.

We have a range of configured accessories such as scanners and printers.

We provide a range of Medical Keyboards and Mice.

Fully configured solutions ensures clinicians can utilise workstations quicker.

Choose from either a Medical All-In-One PC, Laptop, Tablet or Trust PC (powered).

Infinity Cart Range

Our range of mobile carts are unparalleled, and really enhance the all-in-one PC by taking Infinity technology to the point of care. Each cart is below and nearly all can be configured with the all-in-one PC.

Project
All
EPR
ePMA
Theatres
Patient Experience
Maternity
  • Tablet Cart
    Tablet On Wheels For Virtual Visits And More.
    ✓ Compatible With Most Tablets
    ✓ Easy To Manoeuvre
    ✓ Secure Tablet Enclosure
    Learn more
  • UltraLite Cart
    Our Smallest, Thinnest And Lightest Laptop Cart.
    ✓ Height Adjustable
    ✓ Easy To Manoeuvre
    ✓ Slide-Out Mouse Tray
    Learn more
  • EconoLite Cart
    Lightweight, easy to move and simple in design.
    ✓ Height Adjustable
    ✓ Easy To Manoeuvre
    ✓ Slide-Out Mouse Tray
    Learn more
  • VersaLite EPR Cart
    Providing the best of ergonomics and comfort.
    ✓ Height Adjustable
    ✓ Easy To Manoeuvre
    ✓ Comfort Keyboard Tray
    Learn more
  • VersaLite MedDrawer
    One Secure Drawer For More Efficient Dispensing.
    ✓ Height Adjustable
    ✓ Easy To Manoeuvre
    ✓ Lockable Drawer
    Learn more
  • VersaLite ePMA Cart
    Combining ergonomics, comfort and storage.
    ✓ Electric Height Adjustment
    ✓ Comfort Keyboard Tray
    ✓ Organisable Drawers
    Learn more
  • MedStore Extra Cart
    Access varied medication in a compact workstation.
    ✓ Large Storage Capacity
    ✓ Height Adjustable
    ✓ Comfort Keyboard Tray
    Learn more
  • MedStore Plus Cart
    Carry more with our largest capacity workstation.
    ✓ Large Storage Capacity
    ✓ Large Work Surface
    ✓ Organisable Drawers
    Learn more
  • MedRound Cart
    Large Medication Storage With Height Adjustment.
    ✓ Electric Height Adjustment
    ✓ Large Work Surface
    ✓ Large Storage Capacity
    Learn more
  • WardRound Cart
    A sit stand desk that’s mobile and lightweight.
    ✓ Height Adjustable
    ✓ Large Work Surface
    ✓ Easy To Manoeuvre
    Learn more
  • Gaming Kart
    Taking Gaming to the bedside, to keep patients entertained.
    ✓ Playstation, Xbox or other
    ✓ Drawer for accessories
    ✓ Height adjustable
    Learn more
  • Digital Maternity Cart
    Optimise space and keep care focussed on Mum and baby
    ✓ Fixed Height
    ✓ Adjustable Drawers
    ✓ Configurable
    Learn more

Get In Touch

Submit An Enquiry

We’re on hand to quickly give you pricing, more information or arrange a demonstration. Please contact us via the form below or pop onto our instant Live Chat service.
